6' Dual Electric Detachable Planer Mast Cisco
SHIPPING INCLUDED TO LOWER 48 STATE DESTINATIONS
BASE PRICE WITHOUT ELECTRIC CONTROLS INCLUDES SHIPPING $1279.99
Part Number: PMDBE-DM
This planer mast is able is break into two separate 3' sections allowing easy and safe storage of the mast when trailering or when having to quickly clear an obstacle. This detachable kit includes the knurled threaded knobs which secure into a recess hole in the planer mast pole. This ensures no imperfections are made in the aluminum to allow consistently smooth movement when securing and detaching the two mast poles together. A separate mounting base is also included which holds one section of the 3' mast when the two pieces are separated.
Our design allows you to break down the mast without removing or tangling any planer mast board line!
The planer mast includes 6” solid aluminum reels, line guides, variable clutches, aluminum clutch knobs, high torque electric motors with modified output shafts, aluminum cased pulleys, removable base, mounting plate, backing plate, knurled thumbscrews and a separate mounting plate and collar.
12 Volt Motor Specs: Our solid aluminum 6” reels are powered by motors which are engineered and manufactured in the USA; these motors have 2½ times more torque than our competitors making it possible to retrieve any size planer board at any trolling speed.
Attached to the shaft is a heavy duty stainless steel collar which is built for precision adjustments of the clutch (other manufacturers use a thin snap ring which when too much pressure is applied breaks the ring causing the clutch components to rub against the motor housing, thus destroying the unit).
Additionally, we seal our motors through an extensive weatherproofing process to ensure a long lasting life of the motor.
Specs for Reel and Clutch Components: The 6” reel comes with a 7/16” stainless steel bore to fit the driveshaft. Attached to the shaft is also a heavy duty stainless steel collar which is built for precision adjustments of the clutch (other manufacturers use a thin snap ring which when too much pressure is applied breaks the ring causing the clutch components to rub against the motor housing, thus destroying the unit). Our clutch components use a hard anodize pressure plate and 660 bronze machined clutch pads for virtually no wear on the unit even after years of constant abuse. The clutch knob is also solid aluminum and unlike plastic knobs will neither break nor need replaced each season.
Aluminum Cased Pulley Specs:
Cisco pulley’s are constructed with solid aluminum side plates, hard anodized aluminum sheave, stainless steel ball bearings, and bolted together with stainless steel hardware. We manufacture quality products built for a lifetime of use! The sheave is recessed to prevent the line from being captured between the side plate and sheave. The 12/0 swivel is rated by the manufacturer at 1500 lbs (this swivel is constructed in the USA).
Unlike our competitors you will not find a single piece of plastic on our pulleys. This is also why our pulleys do not make any squealing sounds when in use. The stainless steel bearings provide a smooth and silent operation like no other pulley available!
